• Designed for recess mounting.
• Concealed mounting holes.
• Door opens past 180°.
• 10mm clearance from start of flange to beginning of screw hole.
• 316G stainless steel hinge.
• OEM can screw through the hinge into the deck for added strength and durability.
• In-laid gasket ensures a good seal every time.
• Saralon 2 resin Handles with a positive stop and click secured by a 316G stainless steel pin.
• Injection moulded tubs for a lifetime of use.
• UV resistant.
• Made in USA.
• Plano 3600 Series Tackle Inserts.

Cut Out: 286mm x 387mm

Corner Radius: 25mm

Mount Screws: 4mm c/s

Draws: 4

Overall Size (H x W x D): 330mm x 432mm x 278mm
